Basic parameters
Model name
RAV4 Rongfang Dual Engine E 2021 2.5L four-wheel drive flagship Pro
FAW Audi
FAW Toyota
Compact SUV
Energy type
Gasoline
plug-in hybrid
National VI
Time to market
Maximum power (kW)
2021.04
NEDC pure electric cruising range (km)
87
WLTC pure electric cruising range (km)
73
Fast charging time (hours)
-
Slow charging time (hours)
9.5
Fast charging percentage
-
Maximum power(kW)
225
Maximum torque (N·m)
-
Engine
2.5L 180 HP L4
Motor(Ps)
237
gearbox
E-CVT continuously variable transmission
Length*width*height (mm)
4600*1855*1685
body structure
5-door, 5-seater SUV
Maximum speed (km/h)
180
Official 0-100km/h acceleration (s)
7.4
NEDC comprehensive fuel consumption (L/100km)
1.2
Minimum state of charge fuel consumption (L/100km)
5.5
Vehicle warranty
Three years or 100,000 kilometers
First owner warranty policy
-
Body
length (mm)
4600
width (mm)
1855
height (mm)
1685
wheelbase (mm)
2690
front wheelbase (mm)
1595
rear wheelbase (mm)
1610
approach angle (°)
17
departure angle (°)
13
minimum turning radius (m)
5.5
body structure
SUV
door opening method
swing door
number of doors (units)
5
Number of seats (seats)
5
Fuel tank volume (L)
55
Trunk volume (L)
580
Curb weight (kg)
1990
Engine
Engine model
A25F
Displacement (mL)
2487
Displacement(L)
2.5
Intake form
naturally aspirated
Engine layout
horizontal
Cylinder arrangement
L
Number of cylinders (number)
4
Number of valves per cylinder (number)
4
Compression ratio
14
Valve train
DOHC
Bore diameter(mm)
87.5
Stroke(mm)
103.4
Maximum horsepower (Ps)
180
Maximum power(kW)
132
Maximum power speed (rpm)
6000
Maximum torque (N·m)
224
Maximum torque speed (rpm)
3600-3700
Maximum net power (kW)
132
Engine specific technology
VVT-iE、VVT-i
fuel form
plug-in hybrid
fuel grade
No. 92
Fuel supply method
mixed jet
Cylinder head material
Aluminum alloy
Cylinder material
Aluminum alloy
National VI
Time to market
electric motor
Motor type
Permanent magnet/synchronization
Total motor power (kW)
174
Total motor power (Ps)
-
Total torque of motor (N·m)
391
Maximum power of front electric motor (kW)
134
Maximum torque of front electric motor (N·m)
270
Maximum power of rear electric motor (kW)
40
Maximum torque of rear electric motor (N·m)
121
System comprehensive power (kW)
225
System comprehensive power (Ps)
306
Number of drive motors
Dual motor
Motor layout
Front rear
Battery type
Ternary lithium battery
Battery brand
Xinzhongyuan Toyota
Battery cooling method
liquid cooling
NEDC pure electric cruising range (km)
87
WLTC pure electric cruising range (km)
73
Battery energy (kWh)
15.984
Electricity consumption per 100 kilometers (kWh/100km)
14.2
Battery pack warranty
Eight years or 200,000 kilometers
Fast charging function
-
Fast charging time (hours)
-
Slow charging time (hours)
9.5
Fast charging capacity (%)
-
gearbox
Number of gears
Continuously variable speed
Gearbox type
Electronic continuously variable transmission (E-CVT)
abbreviation
E-CVT continuously variable transmission
chassis steering
Drive mode
Front four-wheel drive
four-wheel drive
Electric four-wheel drive
Center differential structure
-
Front suspension type
MacPherson independent suspension
rear suspension type
E-type multi-link independent suspension
Assist type
electric assist
Body structure
Load-bearing
wheel brake
Front brake type
ventilated disc
rear brake type
disc type
Parking brake type
Electronic parking
Front tire specifications
235/55 R19
Rear tire specifications
235/55 R19
Spare tire specifications
Not full size
